lr Sincroclean Eco

LR PRODUCTS SINCROCLEAN

YOUR CLEANING LADY ON STEROIDS

  • Constant flow gear pumps that follows the speed of the press and ink consumption

  • Reversible ink and cleaning dual pump system

  • Eliminates pump pulsation

  • On-demand flow regulation

  • 100% control over the inking and cleaning functions

  • Eliminates ink foaming

  • Savings in compressed air with rapid ROI

SINCROCLEAN Ink Management System with electric pumps

Combined savings in press downtime, ink, solvent and compressed air all make this a no brainer.

IMPROVE PERFORMANCE OF YOUR EXISTING FLEXO PRESS OR LET US ADD IT TO YOUR NEW FLEXO PRESS WITH PERFORMANCE guarantees.

AUTOMATIC INK PUMPING AND ON-PRESS WASH UP SYSTEM WITH ELECTRONIC FLOW REGULATION

The lr.products sincroclean system gives the operator the ability to control the flow of ink and cleaning solution through the closed chamber system under full control. It provides independent regulation for the ink suction return vs. the ink delivery flow, as well as the ink flow variations as required due to the press speed and ink consumption.


Testimonial: Polystar invests in six Sincroclean systems

Emballages Polystar Inc of Montreal, QC is so confident using our technology, they have purchased six Sincroclean Systems for their existing and new flexo presses.

A true, fully-automatic inking and wash-up systems for new or existing Flexo Presses that increases output, reduces operating costs and downtime.


Custom configurations can be tailored to remove “dark zones” of ink waste

Sincroclean® controls the flow of ink at each color station through the enclosed chamber doctor blade according to press speed and ink consumption. Sincroclean® uses dual electric pumps for each color station to control the flow and includes a recirculation feature to conserve cleaning solution during the wash up cycles.

  • The savings in cleaning solutions and compressed air alone can give you a ROI in less than a year.

  • Sincroclean®  reduces air mixing in the ink in the chamber which can cause anilox cell starvation.

  • Sincroclean®  controls the flow of ink at each individual color station through the enclosed chamber doctor blade according to press speed and ink consumption.

  • It controls the flow of the cleaning solution during the cleaning cycle for cleaning the anilox, enclosed chamber, ink hoses, ink pumps and entire system for the next color change without contamination.

  • Reduction in solvent or cleaning solutions by using between 1.5 to 2 gallons of solution per deck for cleaning because of a recirculation and variable speed feature to conserve cleaning solution during the wash up cycles.

  • Not only is the pressure controlled but the cycle time can be chosen by the operator.

  • The new constant/controlled flow pumps not only eliminate pulsation, but dampen down pressure that can cause ink leaks.

  • Example of using electric motors instead of pneumatics the savings in compressed air consumption can give you a ROI in less than a year in energy savings. Savings can vary from plant to plant depending on many factors.

  • For Solvent base inks the addition of a viscosity and temperature control system the ink density plus viscosity is controlled automatically and evaporation is under better control. For extended gamut printing this becomes an important factor to maintain color.

LR Autowash

lr products Autowash

DUAL PUMPS SYNCING TO THAT 80’s MUSIC YOU LOVE

AUTOWASH designed for water base inks and lower cost:

  1. Ink pumping to the chamber, return by gravity

  2. Suction of ink and return into ink bucket

  3. Wash-up with clean water or cleaning solution

  4. Suction of wash-up solution and return to the common collector

  5. Dirty cleaning solution to collector for transfer to recycle.

AUTOMATIC WASH-UP:

  • Control over ink variables

  • For any type of flexo press

AUTOWASH: Ink Management Option with dual pneumatic pumps

The pumping and washing is based on the use of a reversible pneumatic pump for each printing unit. Pneumatic double-pumping systems have serious regulation problems of the synchronism between pumping and suctioning pumps. This technical solution is simple and extremely efficient and trouble-free operation.
The AUTOWASH provides total integration including all possible options for viscosity, temperature and pH automatic control.


Regulated dual inverted control ink flow to significantly reduce pulsation found in single pump systems

Autowash-sincro is a totally new system that effectively regulates two pneumatic pumps and their synchronization. To date, the regulation of two pneumatic pumps have been too complicated. The difficulty in stabilizing two pneumatic pumps, one in impulsion of ink and the other in suctioning mode is well known.

  • sensors in the pump membrane enable our system to monitor the actual movement of each pump that is controlled by the software as to how the equipment is behaving all times. In this way, the electronics of the equipment can detect inconsistency of regulation and of course, detect the failure of any pump.

  • constant flow of ink in the doctor blade is maintained because the equipment incorporates an anti-pulse accumulator system, which at the same time, acts as a heat exchanger for cooling the ink.

  • smart control software by using advanced PLC software. We do not use a PC or any windows based program in order to avoid problems with the operating system and future upgrades not compatible with the hardware. We use an industrial based  PLC, that is faster, more robust and reliable.

  • electronic control and software

By programmable PLC SIEMENS S7 and quick high speed input by system interruptions. This gives the viscocheck equipment a much higher precision and accurate measurement. Some competitive equipment which do not use dedicated electronics and are based in simple PLC systems, have a noticeable lack of accuracy.

  • compact design with no “dark zones to wash” (siphons, traps. ..) and with the proper slope on the piping for having very good drainage, to prevent ink or cleaning solution retention during wash-up. This insures full ink return to the ink bucket saving thousands of dollars in ink waste annually.

  • high efficiency of wash-up, with several cleaning options for achieving a good cleaning with the minimum consumption of solvent or cleaning solution. The washing cycles can be set and adjusted in time according to customer needs.

  • Ethernet connection is possible. This will help in the exchange of data and instructions of the wash-up unit. lr.products) has developed several interfaces for different OEM brands.


Model Compare


LR PRoduct

ELECTRIC PUMP OPTION

  • Using electric motors with “patented” gear pump for solvent inks instead of pneumatics the savings in compressed air consumption can give you a ROI in less than a year in energy savings.

  • Constant/controlled flow pumps not only eliminate pulsation, but dampen down pressure that can cause ink leaks.

  • Common “dark zones are eliminated (siphons, traps. ..) with proper installation tailored for each specific press so that thousands of dollars are saved annually in ink and solvent.

  • Flow of the gear pump is monitored to with an alarm when problems occur.


LR PRODUCTS

PNEUMATIC PUMP OPTION

  • Using pneumatic pumps for water base inks because of the fast drying ink and hardening when dried, pneumatic pumps reduce maintenance of pumps.

  • Constant flow of ink in the doctor blade is maintained because the equipment incorporates a special anti-pulse accumulator system.

  • Common “dark zones are eliminated (siphons, traps. ..) with proper installation tailored for each specific press so that thousands of dollars are saved annually in ink and solvent.

  • Sensors in the pump membrane enable our system to monitor the actual movement of each pump


LR PRODUCTS VISCOCHECK

KEEP YOUR INK AS FLUID AS YOUR PROFIT

  1. dramatic solvent savings with less evaporation

  2. ink rheological properties under control

  3. viscosity changes, no longer caused by temp. changes

  4. provides warming and cooling automatically

  5. in-line exclusive heat exchangers

VISCOCHECK TC Automatic Viscosity Ink Temperature Regulation Management

Optional Features for both the Sincroclean and Autowash-sincro

viscocheck (automatic viscosity control) Option:

  • The addition of a viscosity control system; constant viscosity and ink density can be controlled conventional sensors (dropping body principle)  or electronic sensors (Inkspec or Brookfield sensor) are incorporated into our software,


viscocheck pH (automatic pH regulation when using water base inks) Option:

  • The pH control is done by a continuous reading of the pH value. The viscocheck unit has a special sensor (pH sensor) which has been specifically designed for the pH reading of water-based inks.

Most of the pH sensors have 2 main issues:

  • The sensors require calibration often.

  • When the sensor run “on dry mode” (without ink or water) the sensor is destroyed and the reading isn’t correct any longer.

In order to solve those two issues, Lr.products has been working together with one of the major industry suppliers for those type of sensors. The result is a robust and a printing environment resistant sensor, ready to work in a printing plant, with no calibration problems and failure readings.

The new Lr.pH sensor, has an auto-protection system in order to detect calibration failures. This way, when an alarm is detected by the equipment software, the regulation will turn into manual mode and the operator will be informed that the automatic mode will not come back until a correct sensor calibration will be done. This sensor and the protection algorithm, are (lr.products) patent pending.
